Parasound NewClassic 275 v.2

Two Channel Power Amplifier 2*90watt

1.430,00 Price include 21% VAT Price exclude VAT € 1.181,82

AVAILABILITY: 1 WEEK

RACKMOUNT

Quantity

Features

- 90 watts x 2 into 8 Ω (all channels driven)

- 150 watts x 2 into 4 Ω or 2 Ω (all channels driven)

- 200 watts x 1 bridged into 8 Ω or 4 Ω

- 20 amps peak current per channel

- 2 Ohm stable operation with load selector switch

- Two pairs of speaker outputs with front panel A/B buttons

- Rear-mounted lockout switch disables front A/B buttons

- High pass filter, switchable for 20Hz or 40Hz

- Automatic on/off by DC trigger with looping output

- Automatic on/off by audio signal with 2 sensitivity settings

- Fully discrete circuitry with high current toroid transformer

- Bridging switch for stereo or mono operation

- Efficient, low heat design

- DC Servo and relay protection circuits

- Rear-mounted left and right gain controls

- Standby, channel status and high temperature indicators

- Gold-plated RCA input jacks

- Heavy duty 24k gold-plated 5-way speaker terminals

- 115/230v selector on rear panel

- 1U rack mount kit available separately (Model RMK11)

- Parasound 3 year parts, 3 years labor warranty (For USA and Canada purchases only)

Specifications

- All Channels Driven 90 watts x 2, 8Ω 150 watts x 2, 4Ω 150 watts x 2, 2Ω (Load switch set to 2-3Ω)

- Bridged Mono 200 watts x 1, 8Ω 200 watts x 1, 4Ω (Load switch set to 2-3Ω)

- Current Capacity 20 amps peak per channel

- Frequency Response 20 Hz - 50 kHz, +0/-3 dB, 1 watt

- Dynamic Headroom - 1.3 dB

- Total Harmonic Distortion 0.35% at full rated output 0.025% at average listening levels

- IM Distortion - 0.05 %

- Transient IM Distortion - Not measurable

- S/N Ratio 110 dB at rated output, IHF A-weighted 103 dB at rated output, unweighted 93 dB at 2.828 V output, IHF A-weighted 84 dB at 2.828 V output, unweighted

- Input Impedance - 33 k Ω

- Input Sensitivity 800 mV for full rated output (28dB)

- Inter-Channel Crosstalk 80 dB @1 kHz, 72 dB @10 kHz, 65 dB @ 20kHz

- Damping Factor - Over 150 at 20Hz 12V Trigger Turn On - DC 9 - 12V, 15 mA

- Audio Turn On Quieter: 1 mV Louder: 6 mV

- AC Power Requirement 110 - 120 V / 220 -240 V, 50 - 60 Hz 0.5 watts standby 25 watts Idle (no audio) 350 watts full output

- Dimensions 17-1/4" Wide 16" Deep, with cables connected 2-1/2" High with feet, 1-3/4" panel only (1U) (437 x 406 x 63mm, 44.1 mm panel only)

- Net Weight - 20 lbs (9.1 kg)

Option

Rack Mount Accessory May be Purchased Separately RMK11
