Aurender N20

High Definition Caching Music Streamer Server

€ 13.900,00 Price include 21% VAT Price exclude VAT € 11.487,60

AVAILABILITY: 1 MONTH

FINISH

STORAGE

Quantity

Features

The brand new linear power supply for N20 utilizes 2 transformers, 4 cores for digital audio output part, large audio-grade capacitors, and isolated grounding! It is extremely sophisticated and dead quiet! A power supply this good contributes immediately audible improvements to any audio component.
Grounding for the SPDIF outputs is now isolated by a separate transformer for an even lower noise floor on AES/EBU, Coax RCA & BNC compared to N10.
All new circuit boards populated with higher precision OCXO clock and oscillator exhibiting 4 to 10 times more stability (frequency stability vs. load) than the N10. Musicality, timing, pace and rhythm are greatly enhanced.
Like A30, ACS10 and ACS100, the N20 features a built-in super capacitor-based uninterruptible power supply. This prevents disc and operating system corruption in the event of an abrupt power outage by safely shutting down the system.
A word clock input facilitates syncing N20 with an external word clock.
N20 features a full color 8.8” 1980 x 480 wide screen as found on A30. The chassis size is just slightly taller than the N10 giving it a more substantial appearance.
The N20 is supplied without hard drives installed. As with N100SC and ACS100, hard drives are the customer’s choice. Each of the two rear panel mounting sleds accommodates a 1, 2,4 or 8TB 2.5 inch SSD or up to 4TB 15mm height 2.5inch HDDs. Since users have different storage requirements, we feel this is the best way to satisfy everyone.
Next-generation USB Audio Class 2.0 Module designed with an emphasis on lowering jitter and lowest possible latency.
Like the W20SE and ACS10, the N20 uses a double isolated LAN port for filter out router induced noise.
Double the DRAM (8GB) of the N10 providing ample system resource for added features in the future
Improved and higher capacity SSD for caching. Upgraded to 500GB M2 NVME. N10 uses a 2.5” 240GB SATA.
Available in silver or black finish.

Specifications

- CPU Intel Quad Core

- Front Panel Display 8.8" 1920 x 480 WIDE IPS COLOR LCD

- SSD for System and Cache 500GB M.2 NVME

- DRAM 8GB

- Content Storage: No Storage installed. Two slots for 2.5inch, 15mm/7mm HDD/SSDs

- SPDIF Digital Audio Outputs: x RCA Coax 1 x BNC (75Ω) 1 x TOSLINK up to 24-bit / 192 kHz AES/EBU x 1

- Precision DSD to PCM conversion on SPDIF Output: Up to DSD512 to 88.2/176.4kHz

- WORD CLOCK in:YES

- SPDIF Output Isolation: Isolated By Separate Transformer core Full Linear

- Power Supply: USB Audio Type Module Type

- Data USB 2 x USB 3.0 (Rear)

- Dedicated Audio USB Port 1 x USB AUDIO Class 2.0

- USB Audio Output Specification- PCM Up to 768kHz DSD : DoP - Up to DSD256

- Native - Up to DSD512

- Main Clock Accuracy: OCXO Based Precision Jitter Reducing

- Clock Generator Frequency stability: +/-5x10-9

- Ethernet 1 x Double-Isolated Gigabit Ethernet

- Internal UPS for safe shutdown Super Capacitor Based

- Power Transformer: 1(50W) for CPU, 2(35W,4 cores) for Digital Audio Output

- Dimensions(WHD) and Weight 430 x 111x 353 mm / 13.5 kg

>
