TEAC PE-505

Phono Preamplifier

1.799,00 Price include 21% VAT Price exclude VAT € 1.486,78

AVAILABILITY: 1 WEEK

FINISH

Quantity

Fully-balanced circuit design

From the head amplifier to the equalizing amplifier sections to the buffer amplifier section on the final output stage; the PE-505 employs a fully-balanced circuit design throughout all stages that amplifies, equalizes, and maintains signal purity of even the most extremely faint audio signals picked up by a cartridge. Even unbalanced signal on the conventional RCA input is converted to the differential processing mode right after the input terminals.

Equalizing circuit on the differential cartridge output

Absorbing errors on the balanced output, the differential output equalizing circuit delivers a more accurate audio signal. Signals are equalized for a pure and natural audio signal delivery.

High-precision RIAA circuit

A newly developed NF-type equalizing amplifier achieves less than ±0.05dB of RIAA deviation. (20Hz to 20kHz)

High Signal-to-Noise ratio

The PE-505 achieves 106dB on the RCA input (MM), and 86dB on the XLR input (MC), while the residual noise voltage reaches 10μV on the MM and 85μV on the MC (XLR Input) which are sophisticated.

Features

- Full differential input/outputs circuit

- High-precision RIAA EQ circuit achieves less than ±0.05dB of deviation

- Individual EQ curves for monaural records and those with EQ from DECCA and COLUMBIA

- Balanced MC input

- MC load-impedance measuring, and switchable impedance

- Switchable MM load-impedance capacity (0, 100, 220, 330pF)

- Switchable MM/MC gain (High/Low)

- Subsonic detection, and Subsonic filter

- MONO function that mixes left and right channels as a monaural channel

- DEMAG function that de-magnetizes cartridge

- 3-position pin-point feet

>
