Completely redesigned from scratch, our new integrated amplifier, the 8300A is miles ahead of what was already an industry-leader. Higher power, an additional phono stage and new Audiolab styling means the amplifier is more stylish and more versatile than ever. Most importantly it's new, ultra-efficient circuitry and streamlined components create a listening experience which brings new definition to your favourite music.

Control Where You Need It
The 8300CD adds full digital preamp functionality, with volume and source selection accessible via the player’s front panel and remote handset. This means the 8300CD can be connected directly to a stereo power amp, or a pair of monoblocks like the new Audiolab 8300MB, as well as to a traditional integrated amp like the equally new Audiolab 8300A. 8300 Series also allows control of music playing from a PC/Mac/media device via USB. When connected to a computer, the 8300CD not only identifies itself as an asynchronous DAC, but also as a HID-compatible device (Human Interface Device). This allows driverless control of the PC/Mac/media player (Play, Pause, Stop, Track Select etc).

New Updated Aesthetic
The newly updated external structure of the 8300 series follows the new design aesthetic of Audiolab products going forward, incorporating softened lines and textures yet still maintaining Audiolab’s instantly recognisable and contemporary style. The 8300 series’ blasted aluminium finish, CNC routed aluminium dials and display certainly look cutting-edge, yet with every Audiolab product, form follows function. The new display and controls enable a fast and intuitive access through the vast routing options and filter settings in both the A and CD.

Higher Resolution
The new 8300CD can accept and process data up to 32-bit/384kHz; this is a far higher specification than that required even by current hi-res music formats, ensuring the 8300CD is fully equipped for future advances in ultra-high-definition digital sound. The USB input now also accepts DSD data, as well as PCM. This is a significant addition, as DSD has an important role to play in the developing high-res digital download scene. Accordingly, the filter section now includes four extra filters for DSD playback, allowing the user to optimise the noise floor to suit the performance of the source file and the bandwidth of associated equipment such as amplifiers and loudspeakers. The uprated digital processing associated with the increased resolution at the USB input delivers additional sonic benefits, for both CD replay and other connected digital sources, whatever the resolution of the file. In advancing the capability of the USB input to include files of up to 32-bit/384kHz, the processing of data preceding and within the Sabre DAC has increased the subjective resolution of musical detail and dynamics, resulting in a more energetic and transparent performance that sets a new standard for CD players at this price level.n this area of performance. A final benefit is increased disc stability and reduced susceptibility to resonance, which additionally contributes to the overall improved sound quality.

Amplification Redefined
While striving to achieve the most supreme sound quality, each stage of Audiolab product development is focused on usability. In particular with the 8300A, ensuring simple yet in-depth control, veteran amp designer, Jan Ertner build the amplifier functionality around the new display. This means users can easily find their way around the versatile configurations the amplifier offers, even while being much more advanced than its predecessors. The amplifier can behave as an integrated amplifier, power amplifier, pre-amplifier and a split pre-amplifier - easily paired with a multitude of hi-fi systems. The 8300A works as coherently inside as it does on the outside - By taking a completely new approach to the layout, a dual mono structure means inter-channel interference is minimised. Crucial components processing audio and the power supply are completely separated as far as possible. Our new technology - Active Current Delivery also ensures a completely clean sound up to the point of clipping, then its advanced microprocessor limits the output, which guarantees no audible distortion, even at its louder output of 75W RMS.

Pure Power
The 8300MB is quite possibly the perfect example of Audiolab's goal to effortlessly reproduce music with exquisite detail. Not only is 8300MB an extremely powerful amplifier, offering 250W of pure power with high current drive capability, but it also features a fully balanced power stage. Internally the 8300MB is arranged as two complete power amplifiers which are bridge coupled to the loudspeaker terminals. Each power amplification stage is fed from one of the terminals of the balanced input, therefore the 8300MB operates as a fully balanced amplifier right through to the speaker output. The benefits are a high level of noise rejection and lower transient distortion plus the ability of the amplifier to draw maximum current from the power supply as required to follow the musical waveform accurately. It all adds up to a startlingly vivid and highly impactful musical performance that will put more energy into your loudspeakers as well as control them like never before.


General description: Integrated Amplifier
- Design philosophy and core technology: Dual Mono Power Amp Design
- Display: OLED 128x64 pixels 2.7"
- Controls: Logarithmic Ladder Volume Design
- Finish: Fine Textured Aluminium (Black / Silver)
- Standby Features: Yes
- 12V Trigger: Yes
- Phono: Yes (MM/MC)
- Balanced XLR Input: Yes

Pre-amplifier Section
- Inputs: CD, Video, Tuner, Aux 1, Aux 2, XLR (Balanced) & Phono
- Outputs: 2 x RCA
- Input sensitivity (Phono RIAA): 50K // 100pF
- Input impedance (line inputs): 50K // 100pF
- Input impedance (phono inputs): 47K // 100pF (MM), 100R // 1.5nF (MC)
- Output voltage: 2.3V max. (< 0.02% THD)
- Output impedance: 120 ohm
- Frequency response: (Line): +/- 0.1dB (10Hz - 20kHz) +/- 3.0dB (1Hz - 100kHz)
- Frequency response: (Phono RIAA) +/- 1.0dB (20Hz - 20kHz)
- Channel Imbalance: < 0.2dB (10Hz - 20kHz)
- Total harmonic distortion (THD) Line: <0.001%
- Total harmonic distortion (THD) Phono: <0.002%
- Signal-to-noise ratio (Line): > 107dB, >109dB(A-weighted)
- Signal-to-noise ratio Phono (MM) : > 73dB, > 78dB(A-weighted)
- Signal-to-noise ratio Phono (MC): > 68dB, > 73dB(A-weighted)
- Crosstalk: < 80dB (L-> R & R->L @10KHz)

Power amplifier Section
- Gain: 29dB (20Hz-20KHz)
- Input Sensitivity: 840mV (Power Out = 70W into 8ohm)
- Input impedance: 15K // 100pF
- Rated max power output THD < 1%: 2 x 75W RMS (8 ohm) , 2 x 115W (4 ohm), (Vmains = 230V , THD < 1%)
- Peak output current: +/- 15A
- Frequency response: +/- 0.1dB (10Hz – 20KHz), +/- 3.0dB (1Hz – 100KHz)
- Channel Imbalance: < 0.2dB (10Hz – 20kHz)
- Total harmonic distortion (THD): <0.002% (Power Out= 50W @ 1KHz, BW = 20Hz – 20kHz)
- Signal-to-noise ratio: > 107dB (BW = 20 – 20KHz ), >109dB(A-weighted BW = 20 – 20KHz)
- Damping factor:        >100 (8ohm Load @ 1kHz)
- Inputs: 1 x RCA
- Outputs: Speaker Binding Post Terminals
- Dimensions: 80 x 444 x 330.3mm
- Net weight: 7.8kg
