Atoll IN300

Integrated Stereo Amplifier

Atoll IN300
Atoll IN300
Atoll IN300
Atoll IN300
2.790,00 Price include 21% VAT Price exclude VAT € 2.305,79
DIGITAL BOARD
– converter: AK4490: S/N: 120 dB dynamic 120dB.
– DSD: 2.8MHz and 5,6MHz.
– PCM from 16 bits to 32bits up to 384 kHz on USB (asynchronous).
– Up to 24Bits 192kHz on optical and coaxial.
– USB converter XMOS: XHRA-2HPA  with specific program for PCM and DSD specially developed for ATOLL.

LINK CAPACITORS
Analog stages: Mundorf MKP in a armored shell.
Digital stages: Vishay MKP high sound quality.

POWER STAGES
Double mono with 2x440VA toroidal transformers.
Specific low consumption supply (5VA) for display and logic circuits.
Capacitors: 12x6800uF low ESR high quality designed specifically for ATOLL.
Soft starter stage to avoid current peek.
Internal Supply High End cable (wired according to AC recommendation).

INPUT STAGES
2 volume attenuators: 1 per channel.
High quality Silver Mica capacitors for soft low pass filter (very fast reaction on pulse).
Symmetrical bipolar stages (discrete components).

OUTPUT STAGES
6 MOS FET per channel: 150Wrms/8Ohm,  260Wrms/4Ohm.
Very low feed global back stages that brings dynamic and natural sound.
Very low distortion due to a specific control stage of the driver transistors.

CONNECTIVITY
High quality tellurium copper speakers terminals (ATOLL exclusive design).
High End Speaker cable link.
Gold plated RCA inputs.

INPUTS
Analog:
5 Inputs (with AUX for optional phono stage)
1 BY-PASS Input
1 XLR Input

Digital:
2 Coaxial Inputs
2 Optical Inputs
1 Bluetooth receiver
1 USB-B asynchronous Input

OUTPUTS
1 pair of speakers OUT
2 Pre-out (for sub or additional power amp.)
1 Trigger Output
1 Headphones jack 6.35mm

FEATURES
Balance setup
Global Remote control
Low noise and consumption OLED display
Black or silver front panel

Specifications
Power Wrms/channel: 150 Wrms/8Ω, 260 Wrms/4Ω
Power Supply: 880 VA
Total of capacitors: 86400 µF
Input impedance: 220 kΩ
Dimensions: 440x320x100 mm
Weight: 15 Kg
