Chord Electronics Ultima Pre 2

Reference Preamplifier

€ 19.899,00 Price include 21% VAT Price exclude VAT € 16.445,45

AVAILABILITY: CONTACT US

FINISH

The fully modernised ULTIMA PRE 2 is built to complement stereo systems of the highest order and represents the finest Chord Electronics engineering inside and out. Just as a preamplifier should, the ULTIMA PRE 2 adds nothing to the original waveform and instead preserves it with zero colouration. This is thanks to our latest advances in switch-mode power supply design, developed from aerospace technologies, and our ultra-low-noise proprietary solid-state circuitry which is both carefully shielded and equipped with premium system components. As a result, the ULTIMA PRE 2 is able to achieve unprecedented noise floor performance of -130dB, meaning your source will always sound like your source and nothing else. Where connectivity is concerned, the ULTIMA PRE 2 has hi-fi systems (and more!) covered. Featuring eight inputs, four stereo pairs of XLRs for balanced connections and another four RCA for unbalanced connections, each of these can be gain-matched and individually selected. For outputs, a single stereo pair is available via XLR or RCA, to accommodate a single stereo amplifier such as the ULTIMA 5 or a pair of mono blocks such as the ULTIMA 3s. Naturally, headphone users are catered for, too, for personal and late-night listening with the addition of a high-resolution 6.35mm output on the front fascia. Where system-triggering is important, (allowing the simultaneous start-up of connected equipment from a single button-press), the ULTIMA PRE 2 is equipped with three outputs which should be more than enough for most systems.

Features

- HF Switch Mode Power Supply] HF Switch Mode Power Supply

- Blue Velvet ALPS Potentiometer] Blue Velvet ALPS Potentiometer

- -115dB Signal to Noise Ratio

- Advanced Shielding Technology] Advanced Shielding Technology

- Fully Balanced Circuitry] Fully Balanced Circuitry

- Analogue Signal Path] Analogue Signal Path

- Input/Output Buffering] Input/Output Buffering

- 4x Stereo RCA Inputs] 4x Stereo RCA Inputs

- 4x Stereo XLR Inputs] 4x Stereo XLR Inputs

- 1x Stereo RCA Output] 1x Stereo RCA Output

- 1x Stereo XLR Output] 1x Stereo XLR Output

- Convection Cooled] Convection Cooled

- Included Top Light Ring] Included Top Light Ring

- 12v Trigger On/Off Input/Output] 12v Trigger On/Off Input/Output

- Solid Aluminium Chassis] Solid Aluminium Chassis

Specifications

- Frequency Range: 2.5Hz – 200kHz +/- 3dB

- Total Harmonic Distortion: 0.002% 20Hz – 20kHz

- Intermodulation Distortion: -115dB on all inputs

- Signal to Noise Ratio: -120dB on all inputs

- Channel Separation: 20Hz @ 100dB, 1kHz @ 95dB, 10kHz @ 90dB, 20kHz @ 85dB

- Channel Balance: 0.01dB

- Input Max Voltage: 17v RMS Balanced – 8.5v RMS Unbalanced

- Output Max Voltage: 17v RMS Balanced – 8.5v RMS Unbalanced

- Output Offset: 0mV (Both Channels)

- Potentiometer Performance: 0dB 0.5dB, -20dB 0.2dB, -60dB 0.24dB (13seconds Full Travel)

- Nominal Gain: All inputs subject to six levels of switchable gain – x0.5, x1, x1.5, x2, x2.5, and x3

- Input Impedance: 100 kΩ Balanced – 50 kΩ Unbalanced

- Output Impedance: 100Ω (Short Circuit Protected)

- Operating Voltage: 85v – 270v AC (50Hz – 60Hz) Auto Switching

- Power Consumption: 30w

- Dimensions Without Integra Legs: 420mm (w) x 355mm (d) x 133mm (h)

- Dimensions With Included Integra Legs: 480mm (w) x 355mm (d) x 173mm (h)

- Weight: 18kG

Included Accessories

- ULTIMA PRE 2 Quickstart guide

- Safety instructions

- 10A Mains IEC cable

- Metal IR system remote control

- 2x AAA batteries
